Multi-stage docker builds fail --optimized validation #38893

MarcusDunn · 2025-04-12T01:20:58Z

Before reporting an issue

I have read and understood the above terms for submitting issues, and I understand that my issue may be closed without action if I do not follow them.

Area

dist/quarkus

Describe the bug

Running a dockerfile with --optimized that works with earlier versions fails on newer ones. I believe the commit is: 332bf12.

The error is: A provider JAR was updated since the last build, please rebuild for this to be fully utilized.

This may be similar to #37770, but they seemed to have resolved the issue.

Version

26.2

Regression

The issue is a regression

Expected behavior

This docker image can be run fine with --optimized

Actual behavior

It fails with ERROR: A provider JAR was updated since the last build, please rebuild for this to be fully utilized.

How to Reproduce?

I have the following dockerfile leveraging keycloakify:

FROM node:22@sha256:0e910f435308c36ea60b4cfd7b80208044d77a074d16b768a81901ce938a62dc AS keycloakify_jar_builder

RUN wget -O - https://apt.corretto.aws/corretto.key | gpg --dearmor -o /usr/share/keyrings/corretto-keyring.gpg && \
    echo "deb [signed-by=/usr/share/keyrings/corretto-keyring.gpg] https://apt.corretto.aws stable main" | tee /etc/apt/sources.list.d/corretto.list && \
    apt-get update && \
    apt-get install -y java-21-amazon-corretto-jdk && \
    apt-get install -y maven;

COPY package.json package-lock.json /opt/app/

WORKDIR /opt/app

RUN npm ci

COPY . /opt/app/

RUN npm run build-keycloak-theme

FROM quay.io/keycloak/keycloak:26.2@sha256:87758ff2293c78c942c7a1f0df2bc13e0f943fcf0c0d027c12fdfac54a35d93b

WORKDIR /opt/keycloak
COPY --from=keycloakify_jar_builder /opt/app/dist_keycloak/keycloak-theme-for-kc-all-other-versions.jar /opt/keycloak/providers/
RUN /opt/keycloak/bin/kc.sh build --db=postgres --health-enabled=true --metrics-enabled=true --tracing-enabled=true --features=opentelemetry:v1,multi-site:v1
ENTRYPOINT ["/opt/keycloak/bin/kc.sh"]

After building, running docker run 24f554b83ada start --optimized yeilds:

ERROR: A provider JAR was updated since the last build, please rebuild for this to be fully utilized.

I am not sure what causes this. I think it may have to do with docker COPY messing with timestamps, but don't know enough to be sure.

For now I can run unoptimized, but this is not ideal.

Anything else?

Running docker run <image hash> show-config yeilds:

Current Mode: production
Current Configuration:
        kc.health-enabled =  true (Persisted)
        kc.provider.file.keycloak-theme-for-kc-all-other-versions.jar.last-modified =  1744417140193 (Persisted)
        kc.log-level-org.jboss.resteasy.resteasy_jaxrs.i18n =  WARN (classpath application.properties)
        kc.log-level-io.quarkus.arc.processor.BeanArchives =  off (classpath application.properties)
        kc.log-level-io.quarkus.deployment.steps.ReflectiveHierarchyStep =  error (classpath application.properties)
        kc.tracing-enabled =  true (Persisted)
        kc.log-level-org.infinispan.transaction.lookup.JBossStandaloneJTAManagerLookup =  WARN (classpath application.properties)
        kc.tracing-jdbc-enabled =  true (Persisted)
        kc.log-level-io.quarkus.config =  off (classpath application.properties)
        kc.log-console-output =  default (classpath application.properties)
        kc.metrics-enabled =  true (Persisted)
        kc.log-level-io.quarkus.arc.processor.IndexClassLookupUtils =  off (classpath application.properties)
        kc.db =  postgres (Persisted)
        kc.log-level-io.quarkus.hibernate.orm.deployment.HibernateOrmProcessor =  warn (classpath application.properties)
        kc.optimized =  true (Persisted)
        kc.version =  26.2.0 (SysPropConfigSource)
        kc.features =  opentelemetry:v1,multi-site:v1 (Persisted)
        kc.run-in-container =  true (ENV)

The text was updated successfully, but these errors were encountered:

shawkins · 2025-04-12T14:34:07Z

I am not sure what causes this. I think it may have to do with docker COPY messing with timestamps, but don't know enough to be sure.

I don't think we've seen this behavior before. But our example shows using ADD, instead of COPY, so that the ownership of the provider jar can also be set - maybe there's a difference between ADD and COPY coming into play here https://www.keycloak.org/server/containers#_writing_your_optimized_keycloak_containerfile

kc.provider.file.keycloak-theme-for-kc-all-other-versions.jar.last-modified = 1744417140193 (Persisted)

Out of curiosity could you also determine what the actual last-modified time of the provider jar is at runtime?

bahaa · 2025-04-12T15:10:25Z

I'm not sure this is the cause or not. But I face the same error when I try to build the image on a machine that has Docker version 24.0.2, build cb74dfc, but when I tried to build the same image on a machine with Docker version 27.5.1, build 9f9e405 or Docker version 28.0.4, build b8034c0ed7 it worked just fine.

MarcusDunn · 2025-04-12T18:03:13Z

I'm not sure this is the cause or not. But I face the same error when I try to build the image on a machine that has Docker version 24.0.2, build cb74dfc, but when I tried to build the same image on a machine with Docker version 27.5.1, build 9f9e405 or Docker version 28.0.4, build b8034c0ed7 it worked just fine.

I'm running one of your "working" versions, which is super weird.

docker -v
Docker version 27.5.1, build 9f9e405

Out of curiosity could you also determine what the actual last-modified time of the provider jar is at runtime?

I'm not sure of an easy way to inspect the modified time at runtime. But these are the stats. (Access and Modify matches the unixtime in the config, Change and Birth are after)

stat keycloak-theme-for-kc-all-other-versions.jar
  File: keycloak-theme-for-kc-all-other-versions.jar
  Size: 1763566         Blocks: 3448       IO Block: 4096   regular file
Device: 7ch/124d        Inode: 33870099    Links: 1
Access: (0644/-rw-r--r--)  Uid: (    0/    root)   Gid: (    0/    root)
Access: 2025-04-12 00:19:00.000000000 +0000
Modify: 2025-04-12 00:19:00.000000000 +0000
Change: 2025-04-12 00:35:45.753114012 +0000
Birth: 2025-04-12 00:35:45.747114012 +000

I don't think we've seen this behavior before. But our example shows using ADD, instead of COPY, so that the ownership of the provider jar can also be set - maybe there's a difference between ADD and COPY coming into play here https://www.keycloak.org/server/containers#_writing_your_optimized_keycloak_containerfile

I think I have to COPY, ADD will not work with multi-stage builds.

MarcusDunn · 2025-04-12T18:25:36Z

found a jankier but functional workaround:

# NEW
RUN touch -m --date=@1744481906 /opt/keycloak/providers/keycloak-theme-for-kc-all-other-versions.jar
RUN /opt/keycloak/bin/kc.sh build --db=postgres --health-enabled=true --metrics-enabled=true --tracing-enabled=true --features=opentelemetry:v1,multi-site:v1
ENTRYPOINT ["/opt/keycloak/bin/kc.sh"]

I don't see many drawbacks of this.

bahaa · 2025-04-12T20:21:06Z

@shawkins changing COPY to ADD --chown=keycloak:keycloak --chmod=644 ... didn't fix the issue for me.

dejwsz · 2025-04-15T10:07:52Z

For us this helped in our multi-stage Dockerfile:

Copy everything like provider, themes with chown: COPY --chown=keycloak:keycloak ...
Touch the provider jar and fix its timestamp back in time before optimized build like:

RUN touch -m -t "$(date -u -d '1 hour ago' +%Y%m%d%H%M.%S)" /opt/keycloak/providers/my-test-spi-jar-with-dependencies.jar && /opt/keycloak/bin/kc.sh build

Chown is required to be able to modify the jar timestamp, otherwise you get permission denied error.

bdovaz · 2025-04-15T10:37:06Z

For us this helped in our multi-stage Dockerfile:

Copy everything like provider, themes with chown: COPY --chown=keycloak:keycloak ...

Touch the provider jar and fix its timestamp back in time before optimized build like:
RUN touch -m -t "$(date -u -d '1 hour ago' +%Y%m%d%H%M.%S)" /opt/keycloak/providers/my-test-spi-jar-with-dependencies.jar && /opt/keycloak/bin/kc.sh build
Chown is required to be able to modify the jar timestamp, otherwise you get permission denied error.

It has worked for us but this indicates that somehow it has to be a regression created in 26.2.0.... It doesn't make sense that this has to be done when it was not necessary until now.

shawkins · 2025-04-15T11:55:59Z

it has to be a regression created in 26.2.0

I wouldn't call this a regression as it's working as intended #34665

It seems more like an issue with specific versions of Docker not maintaining file timestamps.

dejwsz · 2025-04-15T12:10:47Z

I did not analyze it too deep but it looks like it is related somehow to the new version of quarkus used in this new release, so 3.17.x (#36501). The reaugmentation process (https://quarkus.io/guides/reaugmentation) which depends on involved files timestamps, I can see in the keycloak sources the flag is used builder.setProperty("quarkus.launch.rebuild", "true"); - so any rebuild should be done during the process? Maybe here in a multi-stage dockerfile setup this "manual" copy of a provider jar messes up too much with the file timestamp and this makes the process break ?

keycloak/quarkus/runtime/src/main/java/org/keycloak/quarkus/runtime/cli/command/Build.java

Line 78 in 4cb4d2d

System.setProperty("quarkus.launch.rebuild", "true");

I mean the image was built just ok for us, only during a keycloak bootstrap we had the message which ended up as error, so it did not start at all because of this.

shawkins · 2025-04-15T12:21:05Z

@dejwsz the checking of provider jar timestamps is purely on the Keycloak side of things #34665

dejwsz · 2025-04-15T12:21:35Z

it has to be a regression created in 26.2.0

I wouldn't call this a regression as it's working as intended #34665

It seems more like an issue with specific versions of Docker not maintaining file timestamps.

Interesting is with 26.1.5 we did not have the issue at all - our Dockerfile was exactly the same with exception to keycloak base image version.

shawkins · 2025-04-15T12:23:12Z

Interesting is with 26.1.5 we did not have the issue at all - our Dockerfile was exactly the same with exception to keycloak base image version.

#34665 was added in 26.2.

dejwsz · 2025-04-15T12:56:07Z

So to summarize (if I understood it well):

If a provider jar is built in a different stage and we copy it, we just need to modify its timestamp to fool the keycloak / quarkus build process ? no other way 8000 to go here
Build a provider jar and keycloak image in a one, common stage and it should work then just fine ?

dejwsz · 2025-04-15T13:51:32Z

it has to be a regression created in 26.2.0

I wouldn't call this a regression as it's working as intended #34665

It seems more like an issue with specific versions of Docker not maintaining file timestamps.

I guess you may be right, we made those builds in gh runners with docker engine 26.x which was reported with this kind of problems. They plan to upgrade it soon: actions/runner-images#11766 what should solve this problem I guess. We did not have the issue in our local system using one of the latest 28.x docker engine.

bahaa · 2025-04-15T15:16:06Z

BTW, upgrading Docker Engine to 28.x didn't fix the issue. Here's the output of docker version on the machine that has the issue:

Client: Docker Engine - Community
Version:           28.0.4
API version:       1.48
Go version:        go1.23.7
Git commit:        b8034c0
Built:             Tue Mar 25 15:07:11 2025
OS/Arch:           linux/amd64
Context:           default
Server: Docker Engine - Community
Engine:
  Version:          28.0.4
  API version:      1.48 (minimum version 1.24)
  Go version:       go1.23.7
  Git commit:       6430e49
  Built:            Tue Mar 25 15:07:11 2025
  OS/Arch:          linux/amd64
  Experimental:     false
containerd:
  Version:          1.7.27
  GitCommit:        05044ec0a9a75232cad458027ca83437aae3f4da
runc:
  Version:          1.2.5
  GitCommit:        v1.2.5-0-g59923ef
docker-init:
  Version:          0.19.0
  GitCommit:        de40ad0

dejwsz · 2025-04-15T15:53:27Z

so my assumption about docker version was wrong in that case - anyway the solution we used shoud not break anything so we will live with it for the moment

dejwsz · 2025-04-16T12:39:02Z

To add more, we tried to build our provider jar and keycloak in the same stage and it also did not help, still the same error. It looks like a docker engine version also has nothing to do with it. So still a kind of puzzle. Anyway timestamp modification for the provider's jar helps.

ibauersachs · 2025-04-16T12:42:24Z

We also ran into this issue and are currently working around it by modifying the file timestamp.

In any case, IMO file timestamps shouldn't be used for this kind of verification. A hash of the jar would be much better suited, or since it's not security relevant here, even a CRC would be enough and more reliable.

dejwsz · 2025-04-16T13:05:27Z

@dejwsz the checking of provider jar timestamps is purely on the Keycloak side of things #34665

so maybe this way of solving it is not the right one then, like on relying on timestamps only

shawkins · 2025-04-16T13:12:48Z

Looking into to this more there are some references that a plain copy or add operation does indeed have counterintuative affects on the mtime of files - it will be one value at build time, then in the image it will be stored as the image creation time.

There are a couple of suggestions for making thing consistent. From https://docs.docker.com/build/ci/github-actions/reproducible-builds/ you can use SOURCE_DATE_EPOCH, it also appears that COPY --link preserves the original file attributes.

Seems like we do need to update our example.

In any case, IMO file timestamps shouldn't be used for this kind of verification. A hash of the jar would be much better suited, or since it's not security relevant here, even a CRC would be enough and more reliable.

I am not sure what motivated the original decision to use timestamps. I believe that it was considered good enough for most most circumstances with out any performance implications. A CRC32 or other fast hash could prevent false positives from changing timestamps, but we'd need to vet the performance. I agree that there aren't security concerns here with a non-cryptographic given that the primary issue would be having something sensitive in the provider jars.

However this situation does seem to be more of a nuance of Docker that can be addressed in other ways.

fruwe · 2025-04-16T14:32:49Z

I'm experiencing the same issue using custom providers in a Docker-based Keycloak deployment.

When I run kc.sh show after a kc.sh build inside a Dockerfile, I get a config line like this:

kc.provider.file.sentry-8.8.0.jar.last-modified =  1744801494000 (Persisted)

However, when I later run kc.sh show-config inside a container started from that image (via docker compose), I see:

kc.provider.file.sentry-8.8.0.jar.last-modified =  1744801494737 (Persisted)

This results in a non-reproducible config and causes Keycloak to detect changes and re-trigger updates at runtime, even though no actual change occurred in the JAR.

After some investigation, it seems the root cause might be Docker’s image layering or file copy mechanism truncating or altering file timestamps slightly during docker build. The same file appears with a slightly different modification time inside the container at runtime.

Would it be possible for Keycloak to:

Normalize timestamps (e.g. truncate to seconds) during the build phase, or
Optionally skip persisting .last-modified metadata, especially if no changes are detected?

This would improve reproducibility in CI/CD pipelines and prevent unnecessary reconfiguration or rebuilds when using Docker.

fruwe · 2025-04-16T14:44:41Z

PS: I used this as a workaround:

RUN find /opt/keycloak/providers -name '*.jar' -exec bash -c ' \
  for f; do \
  epoch_sec=$(stat -c %Y "$f"); \
  touch -d @"$epoch_sec" "$f"; \
  done' bash {} +

MarcusDunn · 2025-04-16T17:12:15Z

from a keycloak perspective, would it be possible to use a checksum of the jar instead of a timestamp? This seems to capture the intent of the check better, but comes with some overhead.

shawkins · 2025-04-16T17:25:07Z

from a keycloak perspective, would it be possible to use a checksum of the jar instead of a timestamp? This seems to capture the intent of the check better, but comes with some overhead.

Beyond the workarounds that can be done on the docker side of things, I see a couple of options for Keycloak:

use a checksum instead. My concern there is that isn't generally needed and adds startup cost that really isn't needed here either.
A system property or option to indicate that the provider directory is read-only to skip this check.
Change the check from an error to a warning - the worst case is that the augmentation state is out-of-date, so people putting in new jars and miss this warning could be initially confused when they see their stuff either not used, or class loading errors.

closes: keycloak#38893 Signed-off-by: Steve Hawkins <shawkins@redhat.com>

closes: #38893 Signed-off-by: Steve Hawkins <shawkins@redhat.com>

* fix: documenting known issues with docker closes: #38801 #38893 * Update docs/guides/server/containers.adoc --------- (cherry picked from commit 68096ee) Signed-off-by: Steve Hawkins <shawkins@redhat.com> Signed-off-by: Steven Hawkins <shawkins@redhat.com> Co-authored-by: Martin Bartoš <mabartos@redhat.com>

…39340) closes: keycloak#38893 Signed-off-by: Steve Hawkins <shawkins@redhat.com> (cherry picked from commit 0ff4cce)

closes: #38893 (cherry picked from commit 0ff4cce) Signed-off-by: Steve Hawkins <shawkins@redhat.com>

With the latest Keycloak version, the timestamps of providers is compared to the timestamp of the latest provider build. When starting keycloak with the `--optimized` flag, keycloak will throw an error when the timestamp of the providers is more recent than it was during the build. > A provider JAR was updated since the last build, please rebuild for this to be fully utilized. As we do not preserve the timestamp in the init script, this error is always thrown when starting keycloak as optimized. This is fixed by preserving the timestamp in the initContainer `cp` commands. see: keycloak/keycloak#38893 Signed-off-by: msvechla <m.svechla@gmail.com>

With the latest Keycloak version, the timestamps of providers is compared to the timestamp of the latest provider build. When starting keycloak with the `--optimized` flag, keycloak will throw an error when the timestamp of the providers is more recent than it was during the build. > A provider JAR was updated since the last build, please rebuild for this to be fully utilized. As we do not preserve the timestamp in the init script, this error is always thrown when starting keycloak as optimized. This is fixed by preserving the timestamp in the initContainer `cp` commands. see: keycloak/keycloak#38893 Signed-off-by: msvechla <m.svechla@gmail.com> Signed-off-by: Marius Svechla <m.svechla@gmail.com>

…39340) closes: keycloak#38893 Signed-off-by: Steve Hawkins <shawkins@redhat.com>

brutaldev · 2025-05-08T13:05:07Z

We are still getting this with 26.2.4-0

The reason being that the build happens on one server and the provider files get copied to a mount which changes their timestamps. When Keycloak tries to start the timestamps will be different despite the provider files being exactly the same. We cannot "touch" the files at the mount point because it's in cloud storage without that functionality.

Is it possible to disable the flakey timestamp check?

shawkins · 2025-05-08T14:06:43Z

Is it possible to disable the flakey timestamp check?

Please start a new issue. As you can see on this one we ultimately decided to document how to touch the files and relaxed the check to be tolerant to ms truncation.

With the latest Keycloak version, the timestamps of providers is compared to the timestamp of the latest provider build. When starting keycloak with the `--optimized` flag, keycloak will throw an error when the timestamp of the providers is more recent than it was during the build. > A provider JAR was updated since the last build, please rebuild for this to be fully utilized. As we do not preserve the timestamp in the init script, this error is always thrown when starting keycloak as optimized. This is fixed by preserving the timestamp in the initContainer `cp` commands. see: keycloak/keycloak#38893 Signed-off-by: msvechla <m.svechla@gmail.com> Signed-off-by: Marius Svechla <m.svechla@gmail.com>

MarcusDunn added kind/bug Categorizes a PR related to a bug status/triage labels Apr 12, 2025

keycloak-github-bot bot added area/dist/quarkus team/cloud-native labels Apr 12, 2025

leona-ya mentioned this issue Apr 12, 2025

keycloak: 26.1.4 -> 26.2.0 NixOS/nixpkgs#398102

Draft

13 tasks

shawkins mentioned this issue Apr 16, 2025

Can't start nightly keycloak build with custom providers #37770

Closed

2 tasks

shawkins added missing/docs Documentation is missing backport/26.2 release/26.3.0 labels Apr 25, 2025

sschu mentioned this issue Apr 25, 2025

Optimised images built on GitHub Actions fail when run in Azure containers #39228

Closed

2 tasks

mabartos linked a pull request Apr 28, 2025 that will close this issue

fix: documenting known issues with docker (#39162) #39215

Merged

shawkins added a commit to shawkins/keycloak that referenced this issue Apr 29, 2025

fix: adding a check for truncated last modified timestamps

16151e8

closes: keycloak#38893 Signed-off-by: Steve Hawkins <shawkins@redhat.com>

shawkins added a commit to shawkins/keycloak that referenced this issue Apr 29, 2025

fix: adding a check for truncated last modified timestamps

4d3a804

closes: keycloak#38893 Signed-off-by: Steve Hawkins <shawkins@redhat.com>

shawkins added a commit to shawkins/keycloak that referenced this issue Apr 29, 2025

fix: adding a check for truncated last modified timestamps

0db0956

closes: keycloak#38893 Signed-off-by: Steve Hawkins <shawkins@redhat.com>

shawkins mentioned this issue Apr 29, 2025

fix: adding a check for truncated last modified timestamps #39340

Merged

vmuzikar pushed a commit that referenced this issue Apr 30, 2025

fix: adding a check for truncated last modified timestamps (#39340)

0ff4cce

closes: #38893 Signed-off-by: Steve Hawkins <shawkins@redhat.com>

shawkins added a commit to shawkins/keycloak that referenced this issue Apr 30, 2025

fix: adding a check for truncated last modified timestamps (keycloak#…

19cce66

…39340) closes: keycloak#38893 Signed-off-by: Steve Hawkins <shawkins@redhat.com> (cherry picked from commit 0ff4cce)

shawkins mentioned this issue Apr 30, 2025

fix: adding a check for truncated last modified timestamps (#39340) #39364

Merged

shawkins added a commit to shawkins/keycloak that referenced this issue Apr 30, 2025

fix: adding a check for truncated last modified timestamps (keycloak#…

2fd046c

…39340) closes: keycloak#38893 Signed-off-by: Steve Hawkins <shawkins@redhat.com> (cherry picked from commit 0ff4cce)

ahus1 pushed a commit that referenced this issue Apr 30, 2025

fix: adding a check for truncated last modified timestamps

4797989

closes: #38893 (cherry picked from commit 0ff4cce) Signed-off-by: Steve Hawkins <shawkins@redhat.com>

github-actions bot added release/26.2.3 and removed backport/26.2 labels Apr 30, 2025

pskopek added the kind/bug Categorizes a PR related to a bug label May 5, 2025

msvechla mentioned this issue May 7, 2025

[bitnami/keycloak] fix: preserve timestamps in init script bitnami/charts#33492

Open

4 tasks

shawkins added a commit to shawkins/keycloak that referenced this issue May 7, 2025

fix: adding a check for truncated last modified timestamps (keycloak#…

1506de3

…39340) closes: keycloak#38893 Signed-off-by: Steve Hawkins <shawkins@redhat.com>

Provide feedback

Saved searches

Use saved searches to filter your results more quickly

Multi-stage docker builds fail --optimized validation #38893

Multi-stage docker builds fail --optimized validation #38893

Multi-stage docker builds fail --optimized validation #38893

Multi-stage docker builds fail --optimized validation #38893

Comments

Before reporting an issue

Area

Describe the bug

Version

Regression

Expected behavior

Actual behavior

How to Reproduce?

Anything else?
