Helpers for Developing Command Line Interfaces
It integrates well with crayon for coloring the boxes or their content,
It can draw rules and boxes to make headers or footers in console output,
and tree structures. It includes a set of Unicode characters, with fallbacks
on systems that do not support them.
Install the stable version from CRAN:
install.packages("cli")Install the development version from GitHub:
source("https://install-github.me/r-lib/cli")library(cli)Inspired by (and mostly copied from) the figures JavaScript project.
#> ✔ tick ☐ checkbox_off
#> ✖ cross ⓧ checkbox_circle_on
#> ★ star Ⓘ checkbox_circle_off
#> ▇ square ❓ fancy_question_mark
#> ◻ square_small ≠ neq
#> ◼ square_small_filled ≥ geq
#> ◯ circle ≤ leq
#> ◉ circle_filled × times
#> ◌ circle_dotted ▔ upper_block_1
#> ◎ circle_double ▀ upper_block_4
#> ⓞ circle_circle ▁ lower_block_1
#> ⓧ circle_cross ▂ lower_block_2
#> Ⓘ circle_pipe ▃ lower_block_3
#> ?⃝ circle_question_mark ▄ lower_block_4
#> ● bullet ▅ lower_block_5
#> ․ dot ▆ lower_block_6
#> ─ line ▇ lower_block_7
#> ═ double_line █ lower_block_8
#> … ellipsis █ full_block
#> … continue ⁰ sup_0
#> ❯ pointer ¹ sup_1
#> ℹ info ² sup_2
#> ⚠ warning ³ sup_3
#> ☰ menu ⁴ sup_4
#> ☺ smiley ⁵ sup_5
#> ෴ mustache ⁶ sup_6
#> ♥ heart ⁷ sup_7
#> ↑ arrow_up ⁸ sup_8
#> ↓ arrow_down ⁹ sup_9
#> ← arrow_left ⁻ sup_minus
#> → arrow_right ⁺ sup_plus
#> ◉ radio_on ▶ play
#> ◯ radio_off ■ stop
#> ☒ checkbox_on ● record
See list_spinners() and get_spinner(). From the awesome
cli-spinners
project.
Simple rule
rule()Double rule
rule(line = 2)Bars
rule(line = "bar2")rule(line = "bar5")Left label
rule(left = "Results")Centered label
rule(center = " * RESULTS * ")Colored labels
rule(center = crayon::red(" * RESULTS * "))Colored label and line
rule(center = " * RESULTS * ", col = "red")Colored line
rule(center = " * RESULTS * ", line_col = "red")Custom line
rule(center = "TITLE", line = "~")More custom line
rule(center = "TITLE", line = "~-", line_col = "blue")Even more custom line
rule(center = crayon::bgRed(" ", symbol$star, "TITLE", symbol$star, " "),
line = "\u2582", line_col = "orange")Default box
boxx("Hello there!")Change border style
boxx("Hello there!", border_style = "double")Multiple lines
boxx(c("Hello", "there!"), padding = 1)Padding
boxx("Hello there!", padding = 1)boxx("Hello there!", padding = c(1, 5, 1, 5))Margin
boxx("Hello there!", margin = 1)boxx("Hello there!", margin = c(1, 5, 1, 5))boxx("Hello there!", padding = 1, margin = c(1, 5, 1, 5))Floating
boxx("Hello there!", padding = 1, float = "center")boxx("Hello there!", padding = 1, float = "right")Text color
boxx(crayon::cyan("Hello there!"), padding = 1, float = "center")Backgorund color
boxx("Hello there!", padding = 1, background_col = "brown")boxx("Hello there!", padding = 1, background_col = crayon::bgRed)Border color
boxx("Hello there!", padding = 1, border_col = "green")boxx("Hello there!", padding = 1, border_col = crayon::red)Label alignment
boxx(c("Hi", "there", "you!"), padding = 1, align = "left")boxx(c("Hi", "there", "you!"), padding = 1, align = "center")boxx(c("Hi", "there", "you!"), padding = 1, align = "right")A very customized box
star <- symbol$star
label <- c(paste(star, "Hello", star), " there!")
boxx(
crayon::white(label),
border_style="round",
padding = 1,
float = "center",
border_col = "tomato3",
background_col="darkolivegreen"
)You can specify the tree with a two column data frame, containing the node ids/labels, and the list of their children.
data <- data.frame(
stringsAsFactors = FALSE,
package = c("processx", "backports", "assertthat", "Matrix",
"magrittr", "rprojroot", "clisymbols", "prettyunits", "withr",
"desc", "igraph", "R6", "crayon", "debugme", "digest", "irlba",
"rcmdcheck", "callr", "pkgconfig", "lattice"),
dependencies = I(list(
c("assertthat", "crayon", "debugme", "R6"), character(0),
character(0), "lattice", character(0), "backports", character(0),
c("magrittr", "assertthat"), character(0),
c("assertthat", "R6", "crayon", "rprojroot"),
c("irlba", "magrittr", "Matrix", "pkgconfig"), character(0),
character(0), "crayon", character(0), "Matrix",
c("callr", "clisymbols", "crayon", "desc", "digest", "prettyunits",
"R6", "rprojroot", "withr"),
c("processx", "R6"), character(0), character(0)
))
)
tree(data, root = "rcmdcheck")An optional third column may contain custom labels. These can be colored as well:
data$label <- paste(data$package,
crayon::blurred(paste0("(", c("2.0.0.1", "1.1.1", "0.2.0", "1.2-11",
"1.5", "1.2", "1.2.0", "1.0.2", "2.0.0", "1.1.1.9000", "1.1.2",
"2.2.2", "1.3.4", "1.0.2", "0.6.12", "2.2.1", "1.2.1.9002",
"1.0.0.9000", "2.0.1", "0.20-35"), ")"))
)
roots <- ! data$package %in% unlist(data$dependencies)
data$label[roots] <- crayon::cyan(crayon::italic(data$label[roots]))
tree(data, root = "rcmdcheck")MIT © RStudio
